CND-360 D Automatic Flow Wrapping Machine
600000 INR/Unit
Product Details:
- Type Wrapping Machines
- Material MS &SS
- Feature Rust Proof Durable Heavy Duty Machine Less Power Consumable Highly Efficient
- Capacity 200 Pcs/min
- Computerized Yes
- Automatic Grade Automatic
- Control System PLC Control
- Click to View more
X
CND-360 D Automatic Flow Wrapping Machine Price And Quantity
- 350000.00 - 800000.00 INR/Unit
- 600000 INR/Unit
- 1 Unit
CND-360 D Automatic Flow Wrapping Machine Product Specifications
- Silver
- MS &SS
- 2 Horsepower (HP)
- 1 Year
- Rust Proof Durable Heavy Duty Machine Less Power Consumable Highly Efficient
- Electric
- Yes
- 400 Kilograms (kg)
- 200 Pcs/min
- PLC Control
- Wrapping Machines
- Automatic
- 220 Volt (v)
- 3920*670*1320 Millimeter (mm)
CND-360 D Automatic Flow Wrapping Machine Trade Information
- INDIA
- 5 Unit Per Month
- 30 Days
- Wooden Case Packing
- Asia Middle East Africa
- All India
- ISO 9001:2015, CE, IEC
Product Description
Our machine is used to pack various kinds of solid commodities such as Soaps, Candies, Ice Cream Cadies, Chocolates, Biscuits, Pastries, Cakes, Noodles , Electrical tap and Hardware products etc.ï
Salient Features:
- Dual frequency conversion control, bag length can be set and cut in one step, saving time and film.
- Interface features easy and quick setting and operation.
- Self failure diagnosis, clear failure display.
- High sensitivity photoelectric eye colour tracing. Numerical input of cuing sealing position for extra accuracy.
- Temperature independent PID more suitable for packaging different materials.
- Positioned stop function, without sticking knife or wasting film.
- Simple driving system, reliable working convenient maintenance.
- A control is realized through software easy or function ad using and technical upgrade.ï
ï
Technical Specifications.
- Film width : Max. 250mm (can be customize according to your requirements)
- Film width Range : 80 - 250mm
- Bag width : 25 -110mm
- Bag Length : Min. 65mm
- Product High : Max. 50mm
- Packing speed : 40 - 200 bags/min
- Power : 220V, 50/60HZ, Single Phase
- Weight : 400kg
- Dimension ( L*W*H) : 3920*670*1320mm
- Film roll diameter : Max. 320mm
